Product Description
The HVPC series medium-voltage capacitors are designed to enhance grid power factor and optimize power quality, made of high-quality materials with excellent electrical performance and long-term stability, reducing line losses and improving system efficiency.
Equipped with built-in smart protection functions, including over-temperature and over-voltage protection, the capacitor ensures safe and reliable operation in complex conditions. Its modular design facilitates installation and maintenance, enhancing overall system benefits across various sectors.
Technical Overview
| Type | Impregnated full-film dielectric |
| Rated Frequency | Single-phase capacitor 1000~14000V |
| Three-phase capacitor 1000~8000V | |
| Rated Capacity | Single-phase capacitor 100~1000kvar |
| Three-phase capacitor 1000~8000V | |
| Rated Frequency | 50/60HZ |
| Average Loss | 0～+5% |
| Insulating Oil | Chlorine-free biphenyl |
| Dielectric | Polypropylene |
| Insulator | 75kV BIL Creepage distance 190mm |
| 95kV BIL Creepage distance 300mm | |
| 150kV BIL Creepage distance 440mm | |
| 150kV BIL Creepage distance 440mm | |
| Temperature Range | -40℃ ~ +55℃ (Class D) |
| Manufacturing Standards | IEC60871-1, GB/T11024-2010 DL/T840-2003 |
| Color | RAL7035 |
Product Highlights
Intelligence and Visualization
Energy Saving and Environmental Protection
High Reliability and Long Lifespan
