Product Description
The SPC series AC/DC contactor is a high-performance electrical switching device suitable for control and protection in AC and DC circuits. Its advanced electromagnetic design ensures efficient, stable performance, reliable in high-current and high-frequency operations, with arc suppression devices for enhanced circuit safety.
The SPC contactor features high inrush current, low noise, and long electrical life, making it ideal for industrial automation, power systems, and transportation. Its compact design facilitates installation and maintenance, with clear status indication simplifying monitoring. It's a crucial component in modern electrical control systems for reliable remote control, load switching, and circuit protection.
Our product portfolio
-
Overview
The SPC1 series AC contactor is a high-performance motor control and power switching device, suitable for controlling motors, transformers, capacitors, and other loads in industrial and commercial power distribution systems. The maximum current capacity of this series contactor can reach 95A, specifically designed for high reliability, long lifespan, and efficient operation.
Technical Parameters
Control Circuit Voltage [Uc] 220 VAC 50/60 Hz Average Impedance 0.8 mΩ -lth 125A 50Hz for power circuit Rated Impulse Withstand Voltage [Uimp] 6kV conforming to IEC 60947 Mechanical Life 4 Million cycles Control Circuit Characteristics AC at 50 / 60 Hz Surge Suppression Module No built-in surge suppression module Heat Dissipation 6...10 Wat 50 / 60Hz Maximum Operating Frequency 3,600 cycles/hour @ 60℃ Minimum Switching Current [Imin] 5mA for signal circuit Insulation Resistance >10 MΩ for signal circuit -
Overview
The SPC2 series AC contactors are high-performance, high-current devices specially designed for industrial power control and switching. They are suitable for controlling motors, generators, transformers, and other high-power loads. With a maximum current rating of up to 800A, this series offers a reliable and stable solution, making it an ideal choice for large industrial systems.
Technical Parameters
Control Circuit Voltage [Uc] 110 VAC 50/60 Hz Average Impedance 0.12 mΩ lth 1000A 50Hz for the power circuit Rated Impulse Withstand Voltage [Uimp] 8kV, complies with IEC 60947 Mechanical Life 5 Million cycles Control Circuit Characteristics AC at 50/60 Hz Rated Insulation Voltage [Ui] Power circuit: 1000 V, complies with IEC 60947-4-1 Heat Dissipation 22W Maximum Operating Frequency 1,200 cycles/hour at 55℃
Product Highlights
High Reliability and Long Lifespan
Intelligence and Visualization
Wide Compatibility
